Vetter Permanent Aspirator
Grounding cable/Adapter/Pump cage
4 - 5
1
2
3
4 - 5
2
3
1
Pos.: Article No. Description Qty.
1 2230 0175 00 Eyelet for grounding cable 2
2 2230 0176 00 Winch wire 0,54
3 2230 0177 00 Cable lug 6
4 2230 0178 00 Hexagon screw 4
5 1700 0212 00 Nut M 6, self locking, A 2 4
8.3 Suction line
2
1
3
4
5
Pos.: Article No. Description Qty.
1 2230 0039 00 Fixed coupling Storz 38, 1 1/4" AG 1
2 2230 0035 00 Angle 90°, 1 1/4" IG, brass 1
3 2230 0175 00 Eyelet for grounding cable 1
4 2230 0037 00 Double nipple 1 1/4" AG, brass 1
5 2230 0149 00 Reducing sleeve 1 1/4" IG - 1 1/2" IG,brass 1
