A. C. MODULAR GENERATOR SYSTEM
Page 9 of 52
Figure 2
System Specifications
MODEL OF
GENERATOR ER-6.2 ER-8 ER-10 ER-110
Generator
Type
Speed
Frequency
Voltage
Amperage
Output
Power
AC Inductive
3600 RPM
60 Hz
240 VAC or
120/240 VAC
52A @ 120 VAC or
26A @ 240 VAC
6.2 KW continuous
7.5 KW peak AC Inductive
3600 RPM
60 Hz
240 VAC or
120/240 VAC
66A @ 120 VAC or
33A @ 240 VAC
8 KW continuous
9 KW peak AC Inductive
3600 RPM
60 Hz
240 VAC or
120/240 VAC
83A @ 120 VAC or
42A @ 240 VAC
10 KW continuous
12 KW peak AC Inductive
3600 RPM
60 Hz
240 VAC or
120/240 VAC
83A @ 120 VAC or
42A @ 240 VAC
10 KW continuous
12 KW peak
Hydraulic
Motor
Maximum
Speed
Motor Shaft
Size
Port Size Gear Type, 8cc
4000 RPM
0.626 inches
9 tooth spline
7/8” – 14 SAE
7/8” – 14 SAE Gear Type, 8cc
4000 RPM
0.626 inches
9 tooth spline
7/8” – 14 SAE
7/8” – 14 SAE Gear Type, 11cc
4000 RPM
0.626 inches
9 tooth spline
7/8” – 14 SAE
7/8” – 14 SAE
Gear Type, 11cc
4000 RPM
0.626 inches
9 tooth spline
7/8” – 14 SAE
7/8” – 14 SAE
Hydraulic
Pump
Operating
Speed
Standard Shaft
Optional Shaft
Mounting
Flange
Displacement
Continuous
Pressure (Max)
Peak Pressure
Standard
Rotation
Dry Weight
Piston w/pressure
compensated control
880-3120 RPM
continuous duty
SAE B 7/8”-13
Tooth Spline
SAE 1” parallel with key
SAE B-2 bolt mount
45cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand
rotation (opposite
engine rotation
available upon request)
46 lbs Piston w/pressure
compensated control
880-3120 RPM
continuous duty
Spline, SAE B 7/8”-13
Tooth Spline
SAE 1” parallel with key
SAE B-2 bolt mount
45cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand
rotation (opposite
engine rotation
available upon request)
46 lbs Piston w/pressure
compensated control
1100-3120 RPM
continuous duty
Spline, SAE B 7/8”-13
Tooth Spline
SAE 1” parallel with key
SAE B-2 bolt mount
45cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand
rotation (opposite
engine rotation
available upon request)
46 lbs Piston w/pressure
compensated control
850-3240 RPM
continuous duty
SAE B-B 1” 15
Tooth Spline
SAE 1¼” parallel with key
SAE B-2 bolt mount
60cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand rotation
(opposite engine rotation
available upon request)
51 lbs
