Principal parts of the machine – SINGER Simple 3116 User Manual
Page 11
15. Horizontal spool pin
24. Handle
25. Presser foot lever
26.
27. Foot speed control
28. Power cord
16. Bobbin winder
17. Handwheel
18. Pattern selector dial
19. Power and light switch
20. Main plug socket
21. Bobbin thread guide
22. Upper thread guide
23. Face plate
Buttonhole stitch balance adjustment slot
4
GB
28
27
Principal parts of the machine
24
15
16
17
18
19
20
21
22
23
25
26
