CONFIGURATION
One DNA100 is used as a programming interface to the DS16. The DNA100 has one RS232 port
for connection to a PC running PROCOM+.
The DNA100 sets up a link between the PC and the DS16 on the RS485 network. The Configuration is
done from the PC and the information is stored in battery RAM in the DS16. When the system is first
installed the RAM must be reset before the system is configured (described earlier in this section).
After configuring the system the DNA100 may be removed.
SYNTAX
TYPEFONT
boldface type
cr
indicates user input
Courier font
indicates output
COMMAND
The command consists of a command word plus one or more parameters.
The command may be entered on one line with the parameters separated by spaces.
>
command par1 par2 par3
cr
The command may be entered in prompt mode with parameters separated by carriage return. The
prompt will indicate what type of parameter value is required.
>
command
cr
Prompt>
par1
cr
Prompt>
par2
cr
Prompt>
par3
cr
>
PROMPT
< >
Angle brackets enclose input parameters.
$
Hexadecimal value (default is decimal).
-
Range of values may be entered.
..
Periods indicate that only ONE value is required from the range of values.
*
Wild card means all values in a range of values.
/
Optional input selection separator.
