April 2012 Digital Network Adapter DNA100
Connect the DATA pair from the network to pins 3 and 6 of the RJ45 wall jack maintaining polarity of the pair.
If a remote power source is being used, the negative side of the supply must be referenced to Earth Ground, as
well as, the CB901 power supply.
J2 - 9 pin (DB9) RS232 signals :
The DNA100 has a RS232 serial port interface, J2, that can connect to a terminal or printer. Check your
terminal, printer or video switcher manual for the correct RS232 connector type, input, output and handshaking
signal connections.
The maximum length for a RS232 cable connecting the DNA100 and other equipment is 50 feet.
A null-modem (LapLink) cable can be used to connect a DNA100 and a laptop or computer together if they are
close enough to each other.
The following is a description of the pinout of the DB9 connector on the DNA100.
J2 SIGNAL DIRECTION/
PIN# NAME DESIGNATION
1 DCD Data Carrier Detect, input.
2 RXD Receive Data, input.
3 TXD Transmit Data, output.
4 DTR Data Terminal Ready, output.
5 GND Signal Ground.
6 DSR Not used.
7 RTS Request to Send, output.
8 CTS Clear to Send, input.
9 RI Not used.
3
