Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
3
DB415
4
DB415
English
2. CONTROLS / LES COMMANDES / CONTROLES
Main unit / Appareil principal / Unidad principal
With the FLIP DOWN PANEL opened /
Ouvrez le PANNEAU RABATTABLE /
Apertura del PANEL ABATIBLE
Display / Afficheur / Visualizador
1
% ¥
6 7 8
3
5
2
! 0 9 # @ $
4
English
Français
Español
DB415
49
Note:
• Be sure to read this chapter referring to the front diagrams of chapter 2. CONTROLS on page 3 (unfold).
1 Open Button
2 A-M (Audio Mode) Button
LD (Loudness) Button
3 POWER Button
FNC (Function) Button
4 ISR (Instant Station Recall) Button
5 DISP (Display) Button
6 RDM (Random) Button
7 RPT (Repeat) Button
8 SCN (Scan) Button
PS/AS (Preset Scan/Auto Store) Button
9 Preset Buttons (1 to 6)
Direct Buttons (1 to 6)
0 Z-EHCR (Z-enhancer) Button
! BND (Band) Button
TOP (Top Play) Button
@ SRCH (Search) Left and Right ( and ) Buttons
# Rotary Knob
$ Play/Pause ( ) Button
MUTE Button
% Eject ( ) Button
¥ CD insertion slot
