12
computer’s USB port. If this port has USB2.0 driver installed, there is
no need to install the USB driver again.
6. If you cannot capture images under the Video Capture program, you
need to set the signal input source as follows: click “Option” “Video
Crossbar”, and then set INPUT as Video Composite In.
USB CAPTURE FOR MAC COMPUTER
Copy the folder “Mac Driver” into Mac hard disk, open the folder and
double click “Empia 1.0.0b2.zip”, the “setup” file appears. Following
the screen notice, click “Next” and finish installation.
Notes:
1. Please connect the Mac computer and visualizer when installing
driver.
2. Please use the USB2.0 cable provided with visualizer.
VIDEO DISPLAY AND CAPTURE
You can capture and control images on the visualizer from a
computer connected with a USB connector.
Click [Start] -> [Program] -> [VideoCap] -> “VideoCapx.xx”
(x.xx is
software’s version) to open the software.
A. Static Images Snap
Click “Capture”—>“Capture Frame”, input the file name in dialog box,
or you can click icon on the toolbar, then input file name in dialog
window. The image file is JPG format.
B. Snap Video Stream
Click “Capture”—> “Start Capture”, input the file name in dialog box,
or click
icon on the toolbar, then input the file name in dialog box.
If you want to set the time limit for the capture, select “Capture”
->“Set Time Limit“ to set the time limit. Click “Start Capture” to start
capture, and click “Stop Capture” or
icon on the toolbar to stop
