I n t r o d u c t i o n
( r e a d
c a r e f u l l y )
Please Note that in the interests of secure packing you may find that some parts of your kit turntable are pre assembled.
Congratulations on choosing the Origin Live Ultra turntable kit. You now have one of the finest sounding turntables
available at any price - not only will it provide an extraordinary level of high performance but also reliability and low
maintenance.
To achieve the full level of performance it is critical that this instruction manual is followed and read fully. There are
aspects of this turntable which run contrary to what you may be expect so before altering anything it is important to have
