Page 78: Ethernet usb2 usb1 remote
-
EXTERNAL TERMINAL INFORMATION
7
ption):
USB1 = USB_REAR1
7.8 REMOTE
eserved Function
/C : Not Connected
No DESCRIPTION
.7 Ethernet / USB
For both 10Base-T and 100 Base-TX.
Note: Definition (under Menu o
USB2 = USB_REAR2
1
N/C (Not Connected)
2
N/C (Not Connected)
3 RX-(Receive
Data-)
4
N/C (Not Connected)
5
N/C (Not Connected)
6 RX+(Receive
Data+)
7 TX-(Transmit
Data-)
8 TX+(Transmit
Data+)
No DESCRIPTION
1 VCC
2
USB DATA -
3
USB DATA +
4 GND
No DESCRIPTION
1, 2, 3, 4, 5, 6, 7, 8
Input Data 1~8
9, 10, 11, 12
Output Data 1~4
15
Time adjust input(slave)
R
N
16
Time adjust output(master)
13, 14, 17, 18, 19, 20, 23
N/C
21, 22
DC +5V Output
24, 25
GND
ETHERNET
USB2
USB1
REMOTE
