9
Introduction Audio Telephone Navigation Index System settings
Screen display
1 Information/status line,
displays active system
2 Icon for inserted cassette in the head unit
3 Icon for inserted audio- or navigation CD in
the head unit
4 Icon for inserted magazine in the CD-changer
5 Telephone:
S: Signal
R: Roaming
R (highlighted): Roaming on non-home type system
6 Signal meter for telephone
7 Displays system settings and functions
8 Menu field for the softkey functions
The information/status line (1) indicates the active sys-
tem (e.g.: FM for radio). The current system settings and
functions displayed appear in the middle of the screen
(7). The menu field for the softkey functions (8) appears
at the bottom of the screen. The functions can be acti-
vated by pressing the softkeys
below the icon.
P82.85-7115-26
