Layout of poly-v-belt drive – Mercedes-Benz R-Class 2006 Owners Manual User Manual
Page 513
512
Technical data
Layout of poly-V-belt drive
R 350
1 Idler pulley
2 Idler pulley
3 Automatic belt tensioner
4 Power steering pump
5 Air conditioning compressor
6 Crankshaft
7 Coolant pump
8 Generator (alternator)
R 500
1 Automatic belt tensioner
2 Power steering pump
3 Air conditioning compressor
4 Crankshaft
5 Coolant pump
6 Generator (alternator)
7 Idler pulley
