206
Controls in detail
Retractable hardtop
Closing luggage cover
Closed luggage cover
1 Luggage cover
2 Zipper
3 Side holder
4 Handle
̈ Pull out luggage cover 1 in direction of
arrow using handle 4.
̈ Hook luggage cover 1 into left and
right side holders 3.
Opening luggage cover
̈ Unhook luggage cover 1 from side
holders 3.
̈ While holding on to handle 4, guide
luggage cover 1 in the opposite
direction of arrow.
Removing luggage cover
Closed luggage cover
1 Luggage cover
2 Zipper
3 Side holder
4 Handle
̈ Fold back the entire length of the zip-
per’s cloth cover.
̈ Completely open zipper 2 while the
luggage cover is closed.
̈ Open luggage cover 1 see “Opening
luggage cover” ( ୴ page 206).
The tensioning clasps are on the left and
right sides of the trunk.
Opened luggage cover
5 Tensioning clasp
6 Retainer spring
