The system analyzes images from the

following cameras:

R

rear view camera

R

front camera

R

two cameras in the exterior rear view

mirrors

The cameras capture the immediate

surroundings of the vehicle. The system

supports you, e.g. when parking or if vision is

restricted at an exit.
The 360° camera images can be shown in full

screen mode or in seven different split-screen

views on the COMAND display. A split-screen

view also includes a top view of the vehicle.

This view is calculated from the data supplied

by the installed cameras (virtual camera).
The seven split-screen views are:

R

top view and picture from the rear view

camera (130° viewing angle)

R

top view and picture from the front camera

(without displaying the maximum steering

wheel angle)

R

top view and enlarged rear view

R

top view and enlarged front view

R

top view and trailer view (vehicles with

trailer tow hitch)

R

top view and pictures from the rearward

facing mirror cameras (rear wheel view)

R

top view and pictures from the forward

facing mirror cameras (front wheel view)

i

The top view and trailer view are available

for vehicles equipped with a trailer tow

hitch.

When the function is active and you shift the

transmission from position D or R to N, you

see the previous view in the COMAND

display. The dynamic guidelines are hidden.
When you change between transmission

positions D and R, you see the previously

selected front or rear view.

Activation conditions

The 360° camera image can be displayed if:

R

your vehicle is equipped with a 360°

camera

R

COMAND is switched on, see the separate

COMAND operating instructions

R

the

360° Camera

function is activated

Activating the 360° camera using the

SYS button

X

Press and hold the W button for longer

than 2 seconds, see the separate COMAND

operating instructions.

Depending on whether position D or R is

engaged, the following is shown:

R

full screen display with the image from

the front camera

R

full screen display with the image from

the rear camera

Activating the 360° camera with

COMAND

X

Press the W button, see the separate

COMAND operating instructions.

X

Select

System

by turning cVd the

COMAND controller and press W to

confirm.

X

Select

360° Camera

and press W to

confirm.

Depending on whether position D or R is

engaged, the following is shown:

R

a split screen with top view and the

image from the front camera or

R

a split screen with top view and the

image from the rear view camera

For further information about the COMAND

Controller, see the separate COMAND

operating instructions.
