KTD-S0051-D Page
7 Specifications
KTAM3874/pITX User's Guide
3.3
Mechanical Specifications
Dimensions
Pico-ITX
TM
form factor 100 x 72 mm ±0.2 mm
Height approx. 26 mm
3.4
Electrical Specifications
Supply Voltage
5V DC ± 5%
Supply Voltage Ripple
Maximum 100mV peak to peak 0 – 20 MHz
Supply Current (Linux
®
)
The power consumption test uses a tool to stress the CPU (100% load) and at the same time another tool to
generate a high graphic throughput. The boards were tested with a HDMI
®
monitor, USB keyboard & mouse
and a 4 GByte microSD
TM
card as boot device.
Variant:
1 GB SDRAM / 4 GB e.MMC
Variant:
2 GB SDRAM / 4 GB e.MMC
Full Load
Idle
Deep Sleep
1)
Full Load
Idle
Deep Sleep
1)
[A]
[W]
[A]
[W]
[A]
[W]
[A]
[W]
[A]
[W]
[A]
[W]
1.18
5.90
0.98
4.90
0.67
3.35
tbd.
tbd.
tbd.
tbd.
tbd.
tbd.
Note:
1)
Added kernel parameter 'single' to U-Boot environment.
