CP
-ASM10-PSB
1.8
4.2.2 FCM (Fan Control Module)
4.2.3 Fan
4.2.4 Backplane
Technical data etc., see Backplane user information.
Supply voltage
Input current +5V
500mA
Dimensions 38mm x 160mm x 25mm (L x W x D)
Interface
4 digital inputs TTL level
2 digital outputs, galvanical separation
with optocoupler
4 counter inputs for fan monitoring
Supply for up to four fans
max. 2,5A
8 measuring inputs NTC
Interface for CMM via I²C-bus
Nominal voltage 24 V
DC
Current consumption 3 x 0,68A
Air volume, unrestricted 3 x 294 m
3
/h
Speed 3800 tr.min -1
Tachometer output Two pulses per revolution
Dimensions 127mm x 127mm x 38mm
4.3 General data
Fuse (max. value)
10 A slow 250V
Test voltages to EN 60950
Approvals
Ambient temperature
Humidity
30 – 80 %, no condensation
Shock and vibrations
according to EN 60068-2-6 and EN 60068-2-27
Protection: IP 20
Overvoltage category II
Protection class 1
Safety
The unit supplied by
Kontron complies with EN 60950
Electromagnetic Compatibility EMC
Typical attenuation of 40 dB for 1 GHz, if shielded front panels are
used.
By assembling additional electronic components the safety and
EMC data may change.
The complete system must then be re-tested to maintain the stated
performance.
Input-Output 4,3 KV
DC
Input - PE 2,2 KV
DC
Output - PE 0,7 KV
DC
Output - Output 0,7 KV
DC
Component VDE UL
Mains/line connector * *
Mains/line switch * *
Power supply * *
Service 0 °C ........+ 40 °C
Storage - 40 °C ...+ 85 °C
