1.2 Description
This microcomputer system consists of mechanics, backplane, fan
and power supply for a microprocessor system based on the CPCI
PICMG2.16bus. This microcomputer packaging system has been
designed for use in laboratories or in a manufacturing environment
where there are no extreme
conditions.
Please check the technical data of any parts which you wish to
assemble; they may restrict the air flow and the temperature.
This unit has no valid approval for the complete unit. This
can only be granted for the complete unit if approval is
granted for individual units or a batch. Such approvals are
carried out by VDE, TÜV, professional boards etc. according
to each application.
CAUTION!
The unit is designed in accordance with protection class 1!
It must therefore be operated only with protective GND/earth
connection!
1.3 Safety instructions
This microcomputer packaging system has been subjected to
extensive testing before delivery. However, this cannot guarantee
that the unit does not get damaged during transit. Check the
packaging and the CPCI unit before applying mains voltage to
ensure that your system can not be destroyed by faulty operating
voltages.
Caution:
The area of the system accessed after removing the mains/line
panels is not a user area! Parts which can be touched may be
exposed to dangerous voltages. Initial testing, completion, final
testing or maintenance and repairs must be carried out by trai-
ned engineers only.
The following tests have to be done before placing the
system in service:
Disconnect the main/line voltage!
At the rear:
Open the fuse holder with a screwdriver.
Is the correct fuse fitted?
The fuse value has been determined at the factory for the
maximal power delivered by the power supply. The fuse
value must be adjusted to the real current of the global
system. Maximum values are 5 A slow.
At the front:
Are front panels mounted to all connector positions and
disk drive apertures?
Are fan front panel and power supplies screwed on
securely?
1.4 Advice
Caution:
- please observe the safety instructions
- read operating instructions before system start-up!
- to be operated only on networks with PE conductor!
- put into service by qualified personnel only!
Safety instructions
are meant to
- save lives
- prevent accidents
- save trouble
Please make sure to keep these operating instructions. They
contain valuable information pertaining to safety.
They
- support operators, users, service staff and technical personnel
during preparatory work, installation and system start-up, and they
help understand the functions of the system
- give hints as to special operating conditions
- explain the displays and control elements
- inform about all essential technical data
Technical changes and upgrades will be implemented without
prior annoucement, provided that they serve technical progress.
This product is intended exclusively for commercial and industrial
applications. It is not designed for use in connection with
life-supporting medical equipment or other critical applications.
This documentation has been prepared and checked with
greatest care. However, we cannot give guarantee for its
complete correctness, for any damage resulting from
misprint or improper use.
In the case of improper use all warranty claims will lapse!
Attention
Danger to life
