CPCI Backplane PD14: CP-ADAP-P47-PB (3U)
RID 24229 PD14, Rev. 01 © 2003 PEP Modular Computers GmbH Page 3
1. CPCI Backplane Introduction
The specific product description provided with this product documentation is part of the PEP’s
CPCI Backplane manual. For further information, in particular regarding general details as well
as safety and warranty statements, refer to the CPCI Backplane Manual, ID 24229.
2. CP-ADAP-P47-PB (3U) Power Distribution
Adapter
The main features of the 3U CP-ADAP-P47-PB power distribution adapter which is designed
for applications requiring input power distribution via power bars are described in the following
table:
Table 1: Distinctive Features of Backplane CP-ADAP-P47-PB (3U)
Feature Specification
Form Factor 3U
Size 39.6*128.7 mm
Number of Slots 1, 4HP PSU slot
Bus Resolution –
Bus Frequency –
Rear I/O Connectivity –
Hot-Swap Capability Yes
Power Supply Connectors
47-pin Positronic PCIH47 (input)
Power bar, 5 terminals (output)
Redundant Power Supply Optional
Flexible Grounding Option Yes
Fan Connector Optional
MSD Connector Optional
PS-ON Connector –
Reset Function Connector –
IPMB Extension Connector Optional (IPMB0)
System MON-CTRL Connector Yes
