Optional system configurations, 1 power supply options – Kontron CP-ADAP-P47-PB (3U) User Manual
Page 10
PD14: CP-ADAP-P47-PB (3U)
CPCI Backplane
Page 10
© 2003 PEP Modular Computers GmbH
RID 24229 PD14, Rev. 01
5.
Optional System Configurations
5.1
Power Supply Options
The design of this power distribution backplane allows for several different power supply op-
tions:
1. The default configuration of a single compatible pluggable power supply.
2. Addition of compatible pluggable power supplies installed either to the left or right of the
backplane.
Option 1 is the standard configuration which is delivered with a 47-contact female Positronic
type power supply connector.
Option 2 requires the installation of an additional power distribution backplane for each addi-
tional power supply.
