CPCI Power Supply PD04: CP3-SVE-M180AC
RID 24139 PD04, Rev. 01 © 2002 PEP Modular Computers GmbH Page 3
1. Introduction
The specific product description provided with this product documentation is part of the PEP’s
CPCI Power Supply manual. For further information, in particular regarding general details as
well as safety and warranty statements, refer to the CPCI Power Supply Manual, ID 24139.
2. 180W M-Type Power Supply Unit
The main features of the 3U M-type, 120V/230V input, 180W output AC/DC power supply unit
CP3-SVE-M180AC are described in the following table:
Table 1: Distinctive Features of Power Supply Unit CP3-SVE-M180AC
Feature Specification
Form Factor 3U
Frontpanel Size 60.96* 133.35 mm
Mechanics 19” rack
Plug-In Compatibility Yes
Power Supply Connector DIN M24/8 connector
Input Voltage
V
US
= 99V..138V AC
V
EU
= 187V..264V AC
Frequency: 50Hz..60Hz
Voltage Switching Autoranging
Output Power 180W
Output Voltages/Currents
V
o1
= +3.3V at 14A
V
o2
= +5.1V at 20A
V
o3
= +12V at 2A
V
o4
= -12V at 1A
Cooling Free convection
Redundant Supply Capability —
Status Indication Separate LEDs for V
o1
..V
o4
Special Feature(s) —
