PD06: CP3-SVE-P200DC CPCI Power Supply
Page 6 © 2002 PEP Modular Computers GmbH RID 24139 PD06, Rev. 01
2.2 Power Supply Connector
Figure 3: Orientation of the Positronic
P-47 Power Supply Connector
The DC input voltage to the power sup-
ply unit and the V1 ... V4 output voltages
from the power supply unit to the back-
plane are connected via a 47-pin
Positronic male power supply connector.
For the pinouts of the Positronic P-47
power supply connector please refer to
the following table.
1
3
5
7
9
11
13
15
17
19
2
4
6
8
10
12
14
16
18
20
21 22 23
24 25 26
27 28 29
30 31 32
33 34 35
36 37 38
39 40 41
42 43 44
45
46
47
