4. Power Supply Connectors
The AC or DC input voltages to the power supply unit and the output voltages from the power
supply unit to the backplane are connected via a power supply connector complying with one
of the following specifications:
Table 3: Further Characteristics of Kontron CompactPCI Standard PSU’s
FF*
IN
PWR
FP*
(HP)
WGHT
(KG)
CON
TYPE
RED
OP P*
LOAD
SHR
IPMI
(OPT)
ACT
COOL
POWER SUPPLY UNIT
3U
AC
8
0.38
M24/8
N
–
–
REQ
CP3-SVE-M76AC
12
1.0
M24/8
N
–
–
NREQ
CP3-SVE-M180AC
8
0.84
P47
Y
Y
Y
REQ
CP3-SVE-P200AC
DC
8
0.297
M24/8
N
-
-
REQ
CP3-SVE-M75DC-24 (new)
8
1.0
M24/8
N
-
-
NREQ
CP3-SVE-M100DC (new)
12
1.0
M24/8
N
–
–
(N)REQ CP3-SVE-M120DC
12
1.0
M24/8
Y
–
–
(N)REQ CP3-SVE-M150DC
8
0.79
P47
Y
Y
Y
REQ
CP3-SVE-P200DC-24V
8
0.84
P47
Y
Y
Y
REQ
CP3-SVE-P200DC
Table 4: Power Supply Connectors
CONNECTOR TYPE
DESCRIPTION
DIN M-SERIES CONNECTORS
3 or 4-pole DIN M-series male power supply connectors
for power throughput to the power supply unit and a 30-
(32-) pole DIN M24/8 male power supply connector for
power reception from the power supply unit (DIN 41612)
POSITRONIC P-SERIES CONNECTORS
Female 47-pin Positronic connector for power supply
from the reverse side of the backplane and a 47-pin
Positronic male power supply connector for power
reception from the power supply unit
Note...
The term ”power supply connector” is used both for the connectors
receiving the backplanes’ power supply and the mating output connec-
tors of the power supply units.
