4 Connector pinout
Kontron Short Description
ETX® Eval-Board
8
4
Connector pinout
4.1
Overview
Note that pin 1 is marked on the bottom of ETX® evaluation board with a quadratic pad.
Pin#
LCD JILI
(LVDS)
JIDI (digital) Floppy (ETX®)
Feature
IrDA
Video Out
Sound
1
LTGIO0
VSYNC
GND
VCC_UL
NC
Y/R
SNDR
2
LCDDO0
R0
DENSEL
GPE2#
NC
GND
GND
3
LCDDO1
R1
GND
BATLOW#
IRTX
C/G
SNDL
4
DIGON
DIGON
NC
GPE1#
GND
GND
AUXAR
5
LCDDO2
R2
GND
RSMRST#
IRRX
COMP/B
MIC
6
LCDDO3
R3
NC
EXTSMI
VCC
GND
AUXAL
7
BIASON
HSYNC
GND
SERIRQ
NC
SYNC
8
LCDDO4
R4
INDEX#
GPCS#
FIR
GND
9
LCDDO5
R5
GND
I2DAT
10
GND
GND
NC
SMBALRT#
11
LCDDO6
G0
GND
I2CLK
12
LCDDO7
G1
DRV
SMBDATA
13
GND
GND
GND
SMBCLK
14
LCDDO8
G2
NC
EXT_PRG
15
LCDDO9
G3
GND
ROMKBCS#
16
JILI_DAT
JILI_DAT
MOT
BATT
17
LCDDO10
G4
GND
KBINH
18
LCDDO11
G5
DIR#
GND
19
JILI_CLK
JILI_CLK
GND
PWGIN
20
LCDDO12
B0
STEP#
GND
21
LCDDO13
B1
GND
PWRBTN#
22
DETECT#
DETECT#
WDATA#
GND
23
LCDDO14
B2
GND
HLEDR
24
LCDDO15
B3
WGATE#
Resistor 330Ω to VCC
25
GND
GND
GND
26
LCDDO16
B4
TRK0#
27
LCDDO17
B5
GND
28
GND
GND
WP#
29
LCDDO18
SHFCLK
GND
30
LCDDO19
EN
RDATA#
31
VCC
VCC
GND
32
VCC
VCC
HDSEL#
33
VCC
VCC
GND
34
VCC
VCC
DSKCHG#
35
BLON#
BLON#
36
GND
GND
37
GND
GND
38
+12V
+12V
39
+12V
+12V
40
+12V
+12V
