AM4020
Introduction
ID 1036-1863, Rev. 3.0
Page 1 - 5
P R E L I M I N A R Y
1.3
System Relevant Information
The following system relevant information is general in nature but should still be considered
when developing applications using the AM4020.
1.4
Board Diagrams
The following diagrams provide additional information concerning board functionality and
component layout.
1.4.1
Functional Block Diagram
The following figure shows the block diagram of the AM4020.
Table 1-1:
System Relevant Information
SUBJECT
INFORMATION
Hardware Requirements
The AM4020 can be installed on any AMC-supporting carrier board or MicroTCA
backplane with the following AMC Card-edge connector port mapping:
•
Common Options Region ports 0-1:
•
Two Gigabit Ethernet SerDes ports
•
Common Options Region ports 2-3:
•
Two Serial ATA ports
•
Fat Pipes Region ports 4-11:
•
Two x4 or eight x1 PCI Express interface
•
Extended Options Region ports 12-13:
•
Two Serial ATA ports
•
Extended Options Region port 14:
•
One Debug port
•
Extended Options Region port 15:
•
One Serial port
•
Extended Options Region ports 17-20:
•
One DisplayPort (on request)
•
Clock:
•
Bidirectional PCI Express reference clock, FCLKA
For further information on the AMC interconnection, refer to Chapter 2.11, “AMC
Interconnection”.
PCI Express Configuration
The AM4020 only supports the PCI Express root complex configuration; non-
transparent bridge functionality is not supported.
Operating Systems
The board is offered with various Board Support Packages including Windows and
Linux operating systems. For further information concerning the operating sys-
tems available for the AM4020, please contact Kontron.
