AM4011 Introduction
ID 1022-1626, Rev. 2.0 Page 1 - 9
P R E L I M I N A R Y
1.5 Technical Specification
Table 1-2: AM4011 Main Specifications
FEATURES SPECIFICATIONS
Processor and Memory
CPU The AM4011 supports the Intel® Core™2 Duo processor L7400 (LV), 1.5 GHz
clock speed, 667 MHz FSB, and 4 MB L2 cache in a 479 µFCBGA packaging.
Please contact Kontron for further information concerning the suitability of
other Intel processors for use with the AM4011.
Memory Main Memory:
• Up to 4 GB registered DDR2 SDRAM memory with ECC running at 400
MHz (PC3200)
Cache structure:
• 64 kB L1 on-die full speed processor cache
• 32 kB for instruction cache
• 32 kB for data cache
• 4 MB L2 on-die full speed processor cache
FLASH Memory:
• Two redundant Firmware Hub (FWH) Flash chips (2 x 1 MB) controlled
by the MMC
Mass Storage Device:
• Up to 8 GB NAND Flash memory optionally available
Serial EEPROM with 64 kbit
Chi
ps
et
Intel® 3100 Intel® 3100 chipset:
• Support for a single Intel® Core™2 Duo processor
• 64-bit AGTL/AGTL+ based System Bus interface at up to 667 MHz
• System Memory interface with optimized support for DDR2 SDRAM
memory at 400 MHz with ECC
• Three x4 PCI Express ports
• RASUM (Reliability, Availability, Serviceability, Usability, and Manage-
ability) features:
• Memory error detection and reporting of 1-bit and 2-bit errors includ-
ing correction of 1-bit failures
• Integrated Memory Scrub Engine, which logs any uncorrectable
memory errors
• Support for automatic read retry on uncorrectable errors
• Memory sparing allows for one memory bank per channel to be held
in reserve and brought on-line if another memory bank in the chan-
nel becomes defective (only supported with 2 GB and 4 GB main
memory configuration)
• Six-Channel SATA 150 interface (only two channels are used)
• USB 2.0 host interface with up to four USB ports available (only two
USB 2.0 ports are used on the AM4011)
• Firmware Hub (FWH) interface support
• Low Pin Count (LPC) interface
• PCI Rev. 2.2 compliant with support for 32-bit/33 MHz PCI operations
(not used on the AM4011)
• Power management logic support
• Enhanced DMA controller, interrupt controller, and timer functions
• System Management Bus (SMBus) compatible with most I²C™ devices
• Two 16550-compatible Serial ports (COM)
