AT8902M Hardware Description
Page 3 - 23 AT8902M User Guide
Table 3-20: Fabric Interface Port Mapping
CLI ID Channel Port LED
0/1 Uplink 1 - -
0/2 Uplink 2 - -
0/3 Uplink 3 - -
0/4 Uplink 4 - -
0/5 1 0 2
0/6 1 1 2
0/7 2 0 3
0/8 2 1 3
0/9 3 0 4
0/10 3 1 4
0/11 4 0 5
0/12 4 1 5
0/13 5 0 6
0/14 5 1 6
0/15 6 0 7
0/16 7 0 8
0/17 8 0 9
0/18 9 0 10
0/19 10 0 11
0/20 11 0 12
0/21 12 0 13
0/22 13 0 14
0/23 14 0 15
0/24 15 0 16
0/25 10 GbE Uplink (optional)
(BCM56x02 or BCM56x04) AMC B2 -
0/26 10 GbE Uplink (optional)
(BCM56x02 or BCM56x04) AMC B2 -
0/27 10 GbE Uplink (optional)
(BCM56x04) AMC B1 -
0/28 10 GbE Uplink (optional)
(BCM56x04) AMC B1 -
