Introduction CP6002
Page 1 - 18 ID 1036-6431, Rev. 3.0
P R E L I M I N A R Y
General
Mechanical 6U, 4HP, CompactPCI-compliant form factor
Power Consumption See Chapter 5 for details.
Temperature Ranges Operational: 0°C to +60°C Standard (depending on processor version
and airflow in the system)
-40°C to +70°C Extended (CP6002-R2-MC) without TPM
Storage: -55°C to +85°C Without hard disk and without battery
Battery 3.0V lithium battery for RTC with battery socket.
Recommended type: CR1632
Temperature ranges:
Operational: -20°C to +70°C
typical (refer to the battery manufacturer’s
specifications for exact range)
Storage: -55°C to +70°C typical (no discharge)
Climatic Humidity 93% RH at 40 °C, non-condensing (acc. to IEC 60068-2-78)
Dimensions 233.35 mm x 160 mm
Board Weight CP6002-R1: 500 g (with heat sink but without mezzanine cards)
CP6002-R1-MC: 500 g (with heat sink but without mezzanine cards)
CP6002-R2:
720 g (with heat sink but without mezzanine cards)
Table 1-2: CP6002 Main Specifications (Continued)
FEATURES SPECIFICATIONS
Note ...
When a battery is installed, refer to the operational specifica-
tions of the battery as this determines the storage tempera-
ture of the CP6002 (See "Battery" below).
Note ...
When additional components are installed, refer to their oper-
ational specifications as this will influence the operational and
storage temperature of the CP6002.
