CP-RIO6-Ax/Bx Introduction
ID 1030-8996, Rev. 2.0 Page 1 - 11
P R E L I M I N A R Y
1.4 Technical Specification
Table 1-2: CP-RIO6-Ax/Bx Main Specifications
CP-RIO6-Ax/Bx SPECIFICATIONS
Front P
anel Interfaces
VGA
(CP-RIO6-A, CP-RIO6-A216) One VGA interface on a 15-pin, D-Sub connector, J22, for connecting a
standard analog monitor
DVI-D
(CP-RIO6-B, CP-RIO6-B216) One DVI-D interface (digital only) on a 29-pin DVI connector, J23, for
connecting a monitor with a DVI-D interface
HDMI
(CP-RIO6-B, CP-RIO6-B216) One HDMI interface on a 19-pin HDMI connector, J21, for connecting a
monitor with a HDMI interface
Ethernet
(CP-RIO6-A, CP-RIO6-B) Two Gigabit Ethernet interfaces implemented as a dual RJ-45 connector,
J19A/B
COM1 One serial RS-232 port on a 9-pin, D-Sub connector, J20
USB Two USB 2.0 interfaces on type A connectors, J17 and J18
HD Audio AD1884A HD audio codec supporting the following ports:
• Mic-In stereo port on a 3.5 mm stereo jack (pink), J16
• Line-In stereo port on a 3.5 mm stereo jack (blue), J16
• Line-Out stereo port on a 3.5 mm stereo jack (green), J16
• S/P-DIF-Out digital port on an optical fiber connector (Toslink), J15
The CP-RIO6-Ax/Bx provides no audio jack detection support.
Onboard Interfaces
SATA Four SATA I interfaces implemented as onboard connectors, J8, J9, J12
and J13, for connecting external SATA devices via a SATA cable
USB Two onboard connectors, J7 and J11, for connecting two USB 2.0 NAND
Flash modules
COM2 One onboard serial port implemented as a 10-pin, 2.54 mm connector, J6
HD Audio AD1884A HD audio codec supporting the following ports:
• CD-In stereo port on a 4-pin onboard connector, J14
• Internal line-out mono port on a 2-pin onboard connector, J10
Fan Two fan connectors, J1 and J2, with PWM control and sense inputs for
monitoring the fan speed.
CompactPCI Three CompactPCI connectors, rJ3, rJ4 and rJ5, for connecting the CP-
RIO6-Ax/Bx to the backplane
