User Guide
CPS3105
In addition, boards ordered with the ruggedized service comply with the following standards as well.
Note: Customers desiring to perform further environmental testing of the CPS3105 must contact
Kontron for assistance prior to performing any such testing.
Boards without conformal coating must not be exposed to a change of temperature which
can lead to condensation, as it may cause irreversible damage especially when the board
is powered up again.
Kontron does not accept any responsibility for damage to products resulting from destruc-
tive environmental testing.
1.5 Related Publications
The following publications contain information relating to this product.
Table 3: Additional Standards for Boards Ordered with Ruggedized Service
TYPE ASPECT STANDARD REMARKS
Environmental Vibration
(Sinusoidal) IEC60068-2-6
IEC61131-2 Ruggedized version test parameters:
9-150 (Hz) frequency range
1 (g) acceleration
1 (oct/min) sweep rate
10 cycles/axis
3 axis
Single Shock IEC60068-2-27
IEC61131-2 Ruggedized version test parameters:
15 (g) acceleration
11 (ms) shock duration half sine
3 number of shocks per direction (total: 18)
6 directions
5 (s) recovery time
Table 4: Related Publications
PRODUCT PUBLICATION
CompactPCI Serial Systems PICMG® CPCI-S.0 R 1.0 CompactPCI® Serial Specification
All Kontron products Product Safety and Implementation Guide, ID 1021-9142
XMC ANSI/VITA 42.0-200x XMC Switched Mezzanine Card Auxiliary Standard
ANSI/VITA 42.3-2006 XMC PCI Express Protocol Layer Standard
