User Guide
CPS3105
1.3 Technical Specif ication
1.4 Standards
This product complies with the requirements of the following standards.
Table 1: CPS3105 Main Specifications
FEATURES SPECIFICATIONS
Switch
PCI Express Switch ExpressLane™ PEX 8712 PCI Express 3.0 switch from PLX Technology used to provide
maximum performance to an XMC module by spitting down the x4 PCI Express 3.0
interface to a x8 PCI Express 2.1/1.0 interface
Co
nnect
or
s XMC XMC connector, J2 (P15), for connecting an XMC module to the CPS3105
CompactPCI Serial CompactPCI Serial interface on connector P1:
» Compliant with PICMG® CPCI-S.0 R 1.0 CompactPCI® Serial Specification
» Support for one x4 PCI Express 3.0 interface
Hot Sw
ap
Hot Swap Hot swap handle with integrated hot swap switch for shutting down the power sup-
plies in order to safely remove the CPS3105 from the system
LED
Front Panel LED Power Status LED:
» Pwr (green): Power Status of the CPS3105
Gener
al
Mechanical 3U, 4 HP, CompactPCI Serial-compliant form factor
Power Consumption approx. 4.7 W (without XMC module)
Power Supply +12V DC in accordance with the CompactPCI® Serial Specification
Temperature Range Operational: 0°C to +60°C Standard
-40°C to +85°C Extended
Storage: -40°C to +85°C Without XMC module
Recommended Airflow Volumetric Flow Rate: > 10 cfm
Sufficient airflow must be provided to ensure optimal operation and long-term
reliability of the CPS3105.
Climatic Humidity 93% RH at 40 °C, non-condensing (acc. to IEC 60068-2-78)
Dimensions 100 mm x 160 mm
Board Weight 140 grams
Table 2: Standards
TYPE ASPECT STANDARD
CE Emission EN55022, EN50121-3-2, EN61000-6-3
Immission EN55024, EN50121-3-2, EN61000-6-2
Electrical Safety EN60950-1
Mechanical Mechanical Dimensions IEEE 1101.10
Environmental Climatic Humidity IEC60068-2-78
WEEE Directive 2002/96/EC
Waste electrical and electronic equipment
RoHS 2 Directive 2011/65/EU
Restriction of the use of certain hazardous sub-
stances in electrical and electronic equipment
