Koala Kare 725-KIT - Manual

Tools Required:
Phillips Head Screwdriver
1. Remove the Child Protection Seat (CPS) from the wall or partition by
unscrewing the mounting screws.
2. Unclip the buckle. Using a Phillips Head Screwdriver, remove the two screws
securing the female section of the buckle to the seat. Remove and discard the
strap and screws.
3. On the right side of the strap (as you look at the seat) there is a threaded
buckle. Unthread the loose end of the strap from the buckle.
4. On the seat back there is a small screw securing the strap to the seat.
Remove this screw using a Phillips Head Screwdriver and discard it. You should
now be able to pull the strap through the slots in the seat back and remove it
from the seat.
5. Take the new strap and thread it through the slot on the left side of the seat
back (as you look at it) and then through the right side slot from the back of the
seat. Make sure not to twist the strap.
6. There will be a small slot in the strap that is now located on the back of the
seat back. Using the Modified Truss Head Screw, secure the strap to the seat
back through the slot in the strap and the screw hole in the seat back.
7. With the free end of the strap, thread the buckle on the strap making sure not
to twist the strap. The free end of the strap should end up on top of the strap.
8. The small section of strap connected to the female end of the strap can now
be threaded through the slot in the seat. Thread the strap from the inside of the
seat to the outside of the seat.
9. Using the two Truss Head Wood Screws, secure the strap through the two
eyelets in the strap to the corresponding screw holes in the seat.
10. Using the mounting hardware that was removed in step one, remount the
CPS following the proper installation instructions that were provided with your
unit.
KB102 CHILD PROTECTION SEAT
REPLACEMENT STRAP INSTRUCTIONS
P/N 725-KIT
Hardware Supplied
Two Truss Head Wood Screws One Modified Truss Head Wood Screw
Koala Kare Products ǁ 6982 S Quentin St. ǁ Centennial, CO 80112 Toll Free: 888.733.3456 ǁ 303.539.8300 ǁ Fax: 303.539.8399
www.koalabear.com
®
P/N 322 December 2010
