Page 2
Parts Included With A/C & P/S Removal Kit
DESCRIPTION
QTY
ALTERNATOR RELOCATION BRACKET
1
M10X40 FLANGE BOLTS (HONDA PART #: 95701-10040-08)
2
ALTERNATOR SPACER(S)
1 or 3
M8X100 FLANGE BOLT (HONDA PART #: 95701-08100-08)
1
M8X50 or M8X70 FLANGE BOLTS
(HONDA PART #: 95701-08050-08 or 95701-08070-08)
2
TENSIONER BRACKET
1
STAINLESS STEEL M8X65 SOCKET HEAD CAP SCREW
1
STAINLESS STEEL M8X20 or M8X30 SOCKET HEAD CAP SCREW
1
TENSIONER BLOCK
1
STAINLESS STEEL M8X25 BUTTON HEAD CAP SCREW
2
M8 LOCK WASHER
2
M8 FLAT WASHER
2
STAINLESS STEEL M8X60 SOCKET HEAD CAP SCREW
1
GATES GLASS-REINFORCED BLACK COMPOSITE IDLER PULLEY
1
BEARING COVER (HONDA PART #: 31185-PCX-003)
1
M10X25 SPECIAL FLANGE BOLT (HONDA PART #: 90031-PRA-000)
1
475K6 or 485K6 V-BELT
1
Tools Required
12mm & 14mm Socket and/or Combination Wrenches
Torque Wrench Capable of 15 ft-lbs (180 in-lbs)
5mm & 6mm Hex Wrenches
Optional Tools
Krikit II V-Belt Tension Gauge
Note: Read all instructions before attempting installation.
If you do not believe you are qualified in performing the
necessary installation, please find an experienced
professional who can.
