11. BATTERY COMPARTMENT:.Remove.
the.cover.to.the.battery.compartment.by.
pressing.the.clip.on.the.right-hand.side.of.
the.cover.and.pulling.it.out..Install.six.“AA”.
alkaline.batteries,.making.sure.to.orient.them.
correctly.as.indicated.by.the.markings.inside..
Reinstall.the.cover.and.you’re.ready.to.go!
12. POWER IN:.This.is.where.you.connect.
the.AC.adapter.to.provide.power.to.the.
Profiler.Model.5.whenever.AC.power.is.avail-
able.to.prolong.the.life.of.the.batteries.
Note:.When.the.AC.adapter.is.connected,.
power.is.automatically.drawn.from.the.AC.
adapter.and.not.from.the.batteries.
13. HEADPHONES:.Use.this.1/8".stereo.
mini.jack.to.connect.headphones.to.the.
Profiler.Model.5.and.monitor.the.stereo.sig-
nal.that.is.playing.in.the.two.speakers..The.
internal.speakers.are.disconnected.when.
headphones.are.used.
Note:.Depending.on.your.headphones,.you.
may.need.to.use.a.stereo.1/8".plug.to.1/4".
jack.headphone.adapter,.available.at.most.
electronic.stores.
14. AUDIO INPUT:.Use.this.1/8".stereo.
mini.jack.to.connect.the.output.from.a.CD.
player,.MP3.player,.laptop,.etc.,.to.the.ampli-
fier..The.stereo.signal.at.the.Audio.Input.is.
summed.with.the.left.and.right.signals.in.the.
amplifier.just.before.the.USB.output.and.the.
Master.volume.control..This.allows.you.to.
play.along.with.your.favorite.music..Use.the.
output.level.control.for.the.signal.source.to.
adjust.the.signal.for.the.proper.mix.with.your.
guitar.
Note:.Depending.on.your.CD.player.or.
other.signal.source,.you.may.need.to.use.an.
adapter.(i.e.,.two.phono.jacks.to.1/8".stereo.
plug),.available.at.most.electronic.stores.
15. USB:.The.USB.(Universal.Serial.Bus).
connector.allows.you.to.connect.the.Profiler.
Model.5.to.a.computer.so.you.can.record.
your.guitar.directly.to.Tracktion.(or.your.
favorite.DAW.application)..Use.a.standard.
USB.cable.(not.supplied).to.make.this.con-
nection.
USB AUDIO
INPUT
DESIGNED IN ST. LOUIS, MO, USA. MANUFACTURED IN CHINA. FABRIQUE EN CHINE
© 2006 LOUD TECHNOLOGIES INC.
“CRATE” IS A REGISTERED TRADEMARK OF LOUD TECHNOLOGIES INC.
US C
3031613
MANUFACTURING DATE SERIAL NUMBER
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE. DO NOT REMOVE COVER. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. AVIS: RISQUE DE CHOC ELECTRIQUE — NE PAS OUVRIR
9VDC 500mA
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES FOR THE U.S. AND
ICES-003, FOR CANADA. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
11
12 13 14 15
The Rear Panel
