Crate Amplifiers 5 - Manual (Page 10)

Profiler Model 5 Compact Stereo Guitar Amplifier with DSP
System Block Diagram
INPUT
TONE GAIN
BUFFER
DIGITALLY CONTROLLED
ANALOG FILTERING AND
DISTORTION CIRCUITRY
MIX
USB
DRIVER
USB
OUT
AMP
ADC DAC
RIGHT
SPEAKER
AUDIO
INPUT
DSP
MIX
AMP
MASTER
LEVEL
LEFT
POWER
AMP
RIGHT
POWER
AMP
HEADPHONE
OUT
HEADPHONE
AMP
AMP MUTE
LEFT
SPEAKER
REVERB
MULTI SINGLE
A-440 Hz
TUNE
CLEAN
MEDIUM GAIN HIGH GAIN
MICROCONTROLLER
PROFILES DELAY
TREM
RTRY
PHSR
CHO
FLNG
WAH/PHSR
WAH
VIBR
OCT DOWN
CHO/PHSR
EFFECTS
10
