CARGO AREA FEATURES

• The cargo load floor system has a load capacity of 400 lbs (181 kg). The load floor

has a built-in storage bin that can hold a variety of items. The underside of the
storage bin cover also contains a plastic-lined tray. The cover can be installed with
either side facing up for added utility.

Cargo Tie-Down Hooks and Loops

• The tie-downs located on the cargo area floor should be used to secure loads safely

when the vehicle is moving.

WARNING!

• Cargo tie-downs are not safe anchors for a child seat tether strap. In a sudden

stop or a collision, a tie-down could pull loose and allow the child seat to come
loose. A child could be badly injured. Use only the anchors provided for child
seat tethers.

• To help protect against personal injury, passengers should not be seated in the

rear cargo area. The rear cargo space is intended for load carrying purposes
only, not for passengers, who should sit in seats and use seat belts.

TRAILER TOWING WEIGHTS (MAXIMUM TRAILER
WEIGHT RATINGS)

Engine/

Transmission

Model

Frontal Area

Max. GTW

(Gross Trailer Wt.)

Tongue Wt.

(See Note)

2.4L/

Automatic

with or with-

out Trailer

Tow Package

FWD or

4WD

32 sq. ft

(2.97 sq. m)

2,000 lbs (907 kg)

200 lbs (91 kg)

3.2L/

Automatic

FWD or

4WD

32 sq. ft

(2.97 sq. m)

2,000 lbs (907 kg)

200 lbs (91 kg)

3.2L/

Automatic

with Trailer

Tow Package

FWD or

4WD

32 sq. ft

(2.97 sq. m)

4,500 lbs

(2 041 kg)

450 lbs (204 kg)

Refer to local laws for maximum trailer towing speeds.

NOTE: The trailer tongue weight must be considered as part of the combined weight of oc-

cupants and cargo, and should never exceed the weight referenced on the Tire and Load-

ing Information placard.

UTILITY

135
