Cavity
Cartridge Fuse
Mini Fuse
Description
M10
15 Amp Blue
Ignition Off Draw — Vehicle Entertain-
ment System (IOD-VES), Satellite
Digital Audio Receiver (SDARS), DVD,
Hands-Free Module (HFM), RADIO,
Antenna (ANT), Universal Garage
Door Opener (UGDO), Vanity Lamp
(VANITY LP)
M11
10 Amp Red
(Ignition Off Draw) IOD-HVAC/ATC,
MW SENSR, Underhood Lamp
(UH LMP)
M12
30 Amp Green
Amplifier (AMP)
M13
20 Amp Yellow
Ignition Off Draw— Cabin Compart-
ment Node (IOD-CCN), Wireless
Control Module (WCM), SIREN,
Multifunction Control Switch
(MULTIFCTN SW)
M14
20 Amp Yellow
Trailer Tow (Export Only)
M15
20 Amp Yellow
COL MOD, IR SNS, Heater Ventilation,
Air Conditioning/Automatic Tempera-
ture Control (HVAC/ATC), Rear View
Mirror (RR VW MIR), Cabin Compart-
ment Node (CCN), Transfer Case
Switch (T-CASE SW), RUN/ST,
Multi-Function Control Switch
(MULTIFTCN SW), Tire Pressure
Monitor (TPM), Glow Plug Module
(GLW PLG MOD) — Export Diesel Only
M16
10 Amp Red
Occupant Restraint Controller (ORC)
M17
15 Amp Blue
Left Tail/License/Park Lamp
(LT-TAIL/LIC/PRK LMP)
M18
15 Amp Blue
Right Tail/Park/Run Lamp
(RT-TAIL/PRK/RUN LMP)
M19
25 Amp Natural
Auto Shut Down (ASD #1 and #2)
M20
15 Amp Blue
Cabin Compartment Node Interior
Light (CCN INT LIGHT), Switch Bank
(SW BANK)
M21
20 Amp Yellow
Auto Shut Down (ASD #3)
M22
10 Amp Red
Right Horn (RT HORN (HI/LOW)
M23
10 Amp Red
Left Horn (LT HORN (HI/LOW)
M24
25 Amp Natural
Rear Wiper (REAR WIPER)
M25
20 Amp Yellow
Fuel Pump (FUEL PUMP), Diesel Lift
Pump (DSL LIFT PUMP) — Export Only
