Cavity Cartridge
Fuse
Mini
Fuse
Description
M3 20 Amp
Yellow
Frt/Rear Axle Locker
Relay
M4 — —
M5 25 Amp
Natural
Power Inverter – If
Equipped
M6 20 Amp
Yellow
Power Outlet #1/Rain
Sensor
M7 20 Amp
Yellow
Power Outlet #2
(BATT/ACC SELECT)
M8 20 Amp
Yellow
Front Heated Seat
M9 20 Amp
Yellow
Rear Heated Seat – If
Equipped
Cavity Cartridge
Fuse
Mini
Fuse
Description
M10 15 Amp
Blue
Ignition Off Draw –
Vehicle Entertainment
System, Satellite Digi-
tal Audio Receiver
(SDARS), DVD,
Hands-Free Module,
RADIO, Antenna,
Universal Garage
Door Opener, Vanity
Lamp
M11 10 Amp
Red
(Ignition Off Draw)
Climate Control Sys-
tem, Underhood
Lamp
M12 30 Amp
Green
Amplifier
7
MAINTAINING YOUR VEHICLE 551
