Engine/
Trans-
mission
Axle Model GCWR (Gross
Combined Wt.
Rating)
Frontal Area Max. GTW
(Gross Trailer
Wt.)
Max. Trailer
Tongue Wt.
(See Note)
3.6L/
Manual
4.10 Four–Door
Rubicon
Model (4WD)
8,406 lbs (3 813 kg) 32 sq ft (2.97 sq m) 3,500 lbs
(1 587 kg)
350 lbs
(159 kg)
3.6L/
Auto-
matic
4.10 Four–Door
Rubicon
Model (4WD)
8,431 lbs (3 824 kg) 32 sq ft (2.97 sq m) 3,500 lbs
(1 587 kg)
350 lbs
(159 kg)
Refer to local laws for maximum trailer towing speeds.
NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo
(ie. the GVWR), and the GVWR should never exceed the weight referenced on the Tire and Loading Infor-
mation placard. Refer to “Tire Safety Information” in “Starting and Operating” for further information.
476 STARTING AND OPERATING
