Jeep 2007 Commander - Manual (Page 399)

Cavity
Cartridge
Fuse
Mini
Fuse
Description
8 10 Amp
Red Lt Park Lamps
9 10 Amp
Red Trailer-Tow Park
Lamps
10 10 Amp
Red Rt Park Lamps
12 20 Amp
Yellow Front Control Module
(FCM) Batt #4
13 20 Amp
Yellow Front Control Module
(FCM) Batt #2
14 20 Amp
Yellow Adjustable Pedal
15 20 Amp
Yellow Ft Fog Lamps
16 20 Amp
Yellow Horn
Cavity
Cartridge
Fuse
Mini
Fuse
Description
17 20 Amp
Yellow Rear Wiper
18 20 Amp
Yellow Front Control Module
(FCM) Batt #1
19 20 Amp
Yellow Lt Trailer-Tow Stop/
Turn
20 20 Amp
Yellow Front Control Module
(FCM) Batt #3
21 20 Amp
Yellow Rt Trailer-Tow Stop/
Turn
22 30 Amp
Pink Final Drive Control
Module (FDCM)
MOD
23 50 Amp
Red Radiator Fan
27 15 Amp
Blue Ignition Off Draw
(IOD) #1
MAINTAINING YOUR VEHICLE 399
7
