Cavity
Cartridge
Fuse
Mini
Fuse
Description
9 40 Amp
Green Pwr Liftgate (XK
Only)
10 40 Amp
Green Starter/Junction
Block (JB) Power
11 30 Amp
Pink Cig Ltr/T-Tow
12 40 Amp
Green Rear Window Defog-
ger (EBL)/Htd Mirror
13 40 Amp
Green Junction Block (JB)
Power
14 50 Amp
Red Cabin Htr 2 (Diesel
Only)
15 50 Amp
Red Cabin Htr 3 (Diesel
Only)
16 25 Amp
Natural Integrated Power
Module (IPM)/Coils
Cavity
Cartridge
Fuse
Mini
Fuse
Description
17 Spare
18 20 Amp
Yellow EATX/AC Clutch
19 20 Amp
Yellow Ign Sw
20 20 Amp
Yellow PCM Batt (Gasoline
Only)
21 30 Amp
Green ABS Valves
22 20 Amp
Yellow T-Tow (BUX)
23 20 Amp
Yellow Final Drive Control
Module (FDCM)
24 20 Amp
Yellow Fuel Pump
MAINTAINING YOUR VEHICLE 397
7
