Front Fog Light (Front Fascia Mounted)
1. Remove the three screws from the backside of the
lamp housing.
2. Pull the bezel and lens away from the lamp housing
far enough to access and disconnect the wiring connector
from the bulb pigtail wire.
3. Pinch together the two hooked ends of the bulb
retainer clip and disengage them from the slots in the
mounting flange on the back of the lens reflector.
4. Pivot the retainer clip up off of the bulb flange and out
of the way.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean
the bulb with rubbing alcohol.
5. Pull the bulb straight out of the mounting flange and
replace the bulb.
