Cavity Fuse Description
F3 50 Amp Red JB Power
F4 40 Amp
Green ABS Pump
F5 20 Amp Yel-
low NGC Trans
F6 30 Amp Pink ASD
F7 50 Amp Red JB Power
F8 40 Amp
Green Ign/Start
F9 50 Amp Red JB Power
F10 30 Amp Pink Trailer Tow
F11 Open
F12 30 Amp Pink Light Bar
F13 40 Amp
Green Windows
F14 40 Amp
Green Ignition Switch
Cavity Fuse Description
F15 50 Amp Red JB Power
F16 Open
F17 Open
F18 Open
F19 30 Amp Pink Rear Window Defogger
(HBL)
F20 Open
F21 20 Amp Yel-
low A/C Clutch
F22 Open
F23 Open
F24 20 Amp Yel-
low Fuel Pump
F25 20 Amp Yel-
low ABS Valves
F26 25 Amp
Natural Injectors
346 MAINTAINING YOUR VEHICLE
