Fat Shark 2 RC Vision Systems
Contents
Product contents ..................................................................................................... 3
Controls ................................................................................................................... 4
Trinity Head tracker ................................................................................................. 5
Downlink Overview (Camera, TX, Power) ............................................................... 6
Transmitter .......................................................................................................... 6
Camera ................................................................................................................ 6
Power (via discharge filter supply) ....................................................................... 7
AV in/out Port .......................................................................................................... 7
Recording Video .................................................................................................. 7
Using an external receiver: .................................................................................. 7
Accessories ............................................................................................................. 7
Pan/Tilt/Roll Mechanism ...................................................................................... 7
1000mA Battery Pack .......................................................................................... 8
Diopter lens ......................................................................................................... 8
Adjustable Earphones ......................................................................................... 8
SpiroNET Circular Polarized Antenna ................................................................. 9
Tiny Telemetry From ImmersionRC .................................................................... 9
Specifications ........................................................................................................ 10
Operational advice ................................................................................................ 11
Warranty ................................................................................................................ 11
Trouble shooting .................................................................................................... 12
Introduction
Congratulations on purchasing the Fat Shark AttitudeV2 FPV video goggles with integrated
NexWaveRF 5G8 wireless receiver and Trinity (3-axis pan/tilt/roll) head tracking technology.
To ensure your continued enjoyment, please take the time to thoroughly read through this
operating manual before using.
Product Compatibility
The AttitudeV2 has been designed to adhere to established video standards and is
compatible with any product also adhering to accepted video standards. Due to the high
number of different manufacturers and variation in quality, it’s impossible to for us to have
tested with every product combination and some troubleshooting may be required if
mix/matching components. The AttitudeV2 has been thoroughly tested with ImmersionRC
gear. For best results and no compatibility issues, Fat Shark recommends ImmersionRC
gear for your accessory products.
IMPORTANT!!!! Product Warning!!!!!
DO NOT LEAVE HEADSET EXPOSED TO DIRECT
SUNLIGHT. SUNLIGHT WILL MAGNIFY THROUGH THE
OPTICS AND BURN HOLES IN THE LCD COLOR FILTER
THIS WILL NOT BE COVERED BY WARRANTY. KEEP
GOGGLES IN PROTECTIVE CASE WHEN NOT IN USE
