- 4 -

A

36"

914mm

B

34

1/4"

870mm

C

21"

533mm

D

33"

838mm

E

24"

610mm

F

16"

406mm

G

37

1/4"

946mm

I

7

1/8"

181mm

J

6

3/4"

171mm

K

10"

254mm

L

13

1/2"

343mm

M

39

3/4"

1010mm

N

55

1/4"

1403mm

O

28

1/8"

714mm

ROD

16

1/2"

419mm

ROW

36

1/2"

927mm

ROH

35"

889mm

FIREPLACE DIMENSIONS

Fig. 2

BHDT36

D

C

G

F

B

J

A

E

F

H

I

K

L

M

Framing Dimensions

ROW

ROH

ROD

N

Appliance Dimensions
