Step 2, Step 3, Fig. 3 – FAB Defense GIS - Glock Scope Mount User Manual
Page 2: Fig. 4
Step 2.
Put your Glock on the right side so that the Slide Stop Lever (6) is facing upwards.
Using a 3 mm Punch push slightly the Trigger Pin (7) half way out from the Slide (Fig 3).
Step 3.
Remove the 3 mm Punch and insert instead the GIS Trigger Pin (2) (Fig. 4).
Push the GIS Trigger Pin (2) until it is fully placed in the Receiver, replacing the original one.
Fig. 3
6
7
Fig. 4
