Glock Scope Mount
-
GIS
Installation Instructions
WARNING!
Make sure your Weapon is unloaded before you begin any
assembly or disassembly procedures.
Fig. 1
Step 1.
Using the 2 mm Alen Key (5) remove from Your GIS the Securing Screws (3)
and the Trigger Pin (2) (Fig. 2).
Parts and Supplied Accessories (Fig 1)
1. Mount Assy
2. Trigger Pin
3. Securing Screws
4. Position Setting Bar
5. 2 mm Alen Key (attached)
1
2
5
4
3
3
Fig. 2
2
