Altivar motor base configuration – ETS-Lindgren 2081 Turntable Manual (Series 2081-2.0, 2081-2.5, 2081-3.0, 2081-4.0, 2081-5.0, 2081-6.0) - (Archived) User Manual
Page 24
Operation
MODEL 2081 TURNTABLE SERIES
20
© ETS-LINDGREN L.P. – JANUARY 2003
REV D – PN 399212
ALTIVAR MOTOR BASE CONFIGURATION
The following settings are the defaults for the Altivar motor base
set by ETS-Lindgren:
Altivar
Setting
208/230 VAC 60 Hz
400 VAC 50 Hz
bFr
60 50
ACC
0.1 0.1
dEC
0.1 0.1
LSP
0 0
HSP
75 75
UnS
230 400
FrS
60 60
tFr
90 90
Should you need to change the configuration on the Altivar motor
base supplied with your turntable the Altivar manual is available at
www.SquareD.com.
Archived 3/18/10
