MODEL 2081 TURNTABLE SERIES Operation
© ETS-LINDGREN L.P. – JANUARY 2003 13
REV D – PN 399212
RECOMMENDED PARAMETERS FOR THE
MODEL 2090 POSITIONING
CONTROLLER
DEVICE 2
Parameter Value Description
P1
0 Turntable
P2
2 Standard Turntable
P3
000 Infinite Scan Count
P5
1 Non-continuous rotation
P8
2.5 2.5 Second reverse delay
P9
9 Primary GPIB address 9
b1
000 User options disabled
c
3608 3600 encoder counts per meter
S0
-1 Step speed = run speed
S1
31 Speed 1 ~12.5% of max speed
S2
63 Speed 2 ~25% of max speed
S3
95 Speed 3 ~37.5% of max speed
S4
127 Speed 4 ~50% of max speed
S5
159 Speed 5 ~62.5% of max speed
S6
191 Speed 6 ~75% of max speed
S7
223 Speed 7 ~87.5% of max speed
S8
255 Speed 8 = max speed
Oc
On Overshoot compensation enabled
Archived 3/18/10
