ETS-Lindgren 6512 Shielded Loop Antenna - Manual (Page 17)

www.ets-lindgren.com Specifications 17
Battery Charger Specifications: Models 6502 and 6507
Input Voltage: 115/230 VAC selectable
Input Frequency: 50/60 Hz
Input Power: 20 VA max
Protection Class: Class II double insulated
Input Fuse Rating: 200 mA time-delay, Type 5x20 mm
Input Power Connection: IEC-320 power inlet
Output Voltage: 12 VDC (13.5–15 VDC)
Output Current: 350 mA
Safety Approvals TUV, CSA
Physical Specifications: All Models
6511 / 6512 6502 6507 6509
Diameter: 56 cm
(22.05 in) 60 cm
(23.62 in) 30.4 cm
(11.97 in) 30.4 cm
(11.97 in)
Height: 59.8 cm
(23.54 in) 67.3 cm
(26.50 in) 37.8 cm
(14.88 in) 47.8 cm
(18.82 in)
Length: 3.8 cm
(1.50 in) 12 cm
(4.72 in) 12 cm
(4.72 in) 7.6 cm
(2.99 in)
Width: 12.7 cm
(5.0 in) 19 cm
(7.48 in) 19 cm
(7.48 in) 8 cm
(3.15 in)
Weight: 1.6 kg
(3.53 lb) 2 kg
(4.41 lb) 1.8 kg
(3.97 lb) 1.3 kg
(2.87 lb)
