Specifications
15
3.0 Specifications
Electrical Specifications
M
ODEL
6502
Frequency Range:
9 kHz—30 MHz
Dynamic Range:
85 dB at 10 kHz
125 dB at 1 MHz
Sensitivity (Typical):
-1 dB (uA/m) at 10 kHz
-42 dB (uA/m) at 1 MHz
1 dB Compression Point:
5 V/m
Power Required:
Battery-operated
Impedance (Nominal):
50 Ω
Connector:
BNC female
M
ODEL
6507
Frequency Range:
1 kHz—30 MHz
Dynamic Range:
76 dB at 10 kHz
116 dB at 1 MHz
Sensitivity (Typical):
11 dB (mA/m) at 10 kHz
-29 dB (mA/m) at 1 MHz
1 dB Compression Point:
10 V/m
Power Required:
13.8 VDC
Impedance (Nominal):
50 Ω
Connector:
BNC female
