Specifications
www.ets-lindgren.com
M
ODEL
6509
Frequency Range:
1 kHz—30 MHz
Band 1:
1 kHz—60 kHz
Band 2:
60 kHz—400 kHz
Band 3:
400 kHz—1 MHz
Band 4:
1 MHz—30 MHz
Maximum Input Power:
1 kW
Impedance (Nominal):
Varies with frequency
(calibrated in a 50 Ω system)
Connector:
Type N female
M
ODELS
6511
AND
6512
Model 6511
Model 6512
Frequency Minimum:
20 Hz
9 kHz
Frequency Maximum:
5 MHz
30 MHz
Turns
8
1
Connectors:
BNC female
Maximum Input
Power:
20 W
Polarization:
Linear
